DCR-2025PRO 2.2x High Definition telephoto Conversion Lens
DCR-2025PRO lens extends the focal length of Canon PowerShot G9/G7 zoom
lens to 460mm powerful telephoto ! (35mm film equivalent) It's a completely
new high definition lens made of the high index optical lens with a 2-group/4-element
formula.
260 lines/mm resolution power at center (MTF30%)
Model LA-DC58H Canon lens adapter and RA6258 Raynox adapter ring are required
for use with the DCR-2025PRO + PowerShot G9/G7 camera.
Magnification: Nominal 2.2x Actual 2.2x / Diagonal, 2.2x / Horizontal
Minimum focusing distance: 2.5m
Zoom capability: Max. telephoto(6x)
Lens construction: 2G/4E Optical coated glass elements
Mounting threads: 62mm
Front filter size: 82mm
Size/Weight: 123 x 85mm/275g.(9.7oz)
DCR-2025PRO comes with 4-adapter rings for 43mm(RA6243), 52mm(RA6252), 55mm(RA6255), 58mm(RA6258) filter sizes and a LS-082 lens shade.
Specifications
 |
 |
|
|
Click camera for actual comparison images. |
 |
Click camera for actual comparison images. |
DCR-1850PRO(BL) Black model 1.85x
The DCR-1850PRO(BL) converts the PowerShot G9/G7 lens to 380mm (35mm film equiv.) focal length when attached at the maximum
telephoto position.
200 lines/mm resolution power at center (MTF30%)
Model LA-DC58H Canon lens adapter and RA5258A Raynox adapter ring are required for use with the DCR-1850PRO + PowerShot G9/G7 camera.
Magnification: Nominal1.85x
Actual1.85x/Diagonal, 1.85x/Horizontal
Minimum focusing distance: 2m
Zoom capability: 2.5x - 6x
Lens construction: 3G/3E Optical coated glass elements Mounting threads
: 52mm
Front filter size: None
Size/Weight: 85 x 58mm/265g(9.3oz)
RA5258A adapter ring is Not Included.
Specifications
Production discontinued.(Sep. 2007) |
DCR-1542PRO 1.54x
High Definition telephoto Conversion Lens
DCR-1542PRO lens extends the focal length of PowerShot G9/G7 camera zoom
lens to 320mm telephoto lens! (35mm film equivalent) It's a completely
new high definition lens made of the high index optical lens with a 2-group
/4-element formula.
340 lines/mm resolution power at center (MTF30%)
Model LA-DC58H Canon lens adapter and RA5258A Raynox adapter ring are required
for use with the DCR-1542PRO + PowerShot G9/G7 camera.
Magnification: Nominal 1.54x
Actual: 1.54x / Diagonal, 1.54x / Horizontal
Minimum focusing distance: 1.5m
Zoom capability: 3.5x - 6x
Lens construction: 2G/4E Optical coated glass elements
Mounting threads: 52mm
Front filter size: 67mm
Size/Weight: 71 x 67mm/240g(8.5oz)
Specifications
RA5258A adapter ring is Not included.
|
|
|
|
Click camera for actual comparison images.
|
|
HD-7000PRO High Definition Wideangle
Conversion Lens 0.7x
The lens creates super wide angle view of f=24.5mm (35mm film equiv.), compatible whole zoom range when mounted on the G9/G7 camera. HD-7000PRO lens controls the image distortion percentage at the least, less than -2.3%.
540 lines/mm resolution power at center (MTF30%)
Model LA-DC58H Canon lens adapter is required for use with the HD-7000PRO
+ PowerShot G9/G7 camera.
Magnification: Nominal 0.7x
Actual 0.7x/Diagonal, 0.7x/Horizontal
Minimum focusing distance: 30mm
Zoom capability: 1x - 6x
Lens construction: 3G/3E Optical coated glass elements
Mounting threads: 58mm
Front filter size: 82mm
Size/Weight:: 87 x 36mm/314g(11oz)
* Slight vignetting may occure in max. wideangle mode.
|
|
|
|
Click camera for actual comparison images. |
|
Click camera for actual comparison images. |
DCR-CF187PRO High Definition 185º Circular Fish-Eye Conversion Lens
Upon mounting on the zoom lens, The DCR-CF187PRO opens the field of view
to circular fisheye image. It's a completely new high definition lens made
of the high index optical coated lens with a 4-group/6-element formula
to obtain the maximum resolution power of 500 lines/mm at center (MTF30%), while it has low dispersion.
Model LA-DC58H Canon lens adapter and RA6258 Raynox adapter ring are required
for use with the DCR-CF187PRO + PowerShot G9/G7 camera.
Magnification: Nominal 185-degree, Actual 185-degree/Diagonal, 185-degree/Horizontal
Minimum focusing distance: 30mm
Zoom capability: 1x - 6x
Lens construction: 4G/6E, made of optical glass lenses, all surfaces fully
coated.
Mounting threads: 62mm
Front filter size: None
Size / Weight: 96 x 98 / 560g(20oz)
RA6258, RA6255, RA6252 and RA6243 adapter rings are Included.
Specifications
|
DCR-FE181PRO Fish-Eye(Full Frame) Lens
DCR-FE181PRO lens captures an amazing ultra-wideangle view of 180 degrees
on diagonal line at the wideangle position f=9mm). It's a completely new
high definition lens made of the high index optical lens with a 4-group/5-element
formula.
480 lines/mm resolution power at center (MTF30%)
Model LA-DC58H Canon lens adapter and RA6258 Raynox adapter ring are required for use with the DCR-FE181PRO + PowerShot G9/G7 camera.
Magnification: Nominal 0.24x
Actual 180-degree/Diagonal
Minimum focusing distance: 30mm
Zoom capability: 1x - 6x
Lens construction: 4G/5E Optical coated glass elements
Mounting threads: 62mm
Front filter size: None
Size/Weight: 100 x 69mm/685g(24oz)
RA6258, RA6255, RA6252 and RA6243 adapter rings are Included.
Specifications
|
|
|
|
Click camera for actual comparison images.
|
|
DCR-5320PRO 3-in-1High Definition
Triple Macro Conversion Lens
The DCR-5320PRO Macro Close-up lens is made of two independent lenses of
2-diopter magnification and 3-diopter one, both fabricated in doublet formula
for less color aberration at corners. By putting the two lenses together,
it creates the high 5-diopter magnification macro close-up conversion lens
with the excellent high resolution power of 200 lines/mm at center (MTF30%).
Model LA-DC58H Canon lens adapter and RA7258 Raynox adapter ring are required
for use with the DCR-5320PRO + PowerShot G9/G7 camera.
Magnification:5-Diopter, 3-Diopter, 2-Diopter
Focusing distance/Zoom capability:
5-Diopter(∞) - 170mm/1.5x - 6x
3-Diopter(∞) - 311mm/1.3x - 6x
2-Diopter(∞) - 486mm/1x - 6x
Lens construction: 3G/5E Optical coated glass elements
Mounting threads: 72mm
Front filter size: 72mm
RA7258 adapter ring is Not Included.
Specifications
|
|
|
|
Click camera for actual comparison images. |
|
Click camera for actual comparison images. |
DCR-150 Macro/Close-Up lens
You can simply "Snap On" DCR-150 Macro lens onto the filter threads
of LA-DC58H Canon lens adapter.
Shooting distance from the object ; 210mm(∞) in maximum telephoto zoom.
Magnification: 4.8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Zoom capability: 3x - 6x
Front filter size: 49mm
Rear threads size: 43mm
Size/Weight: DCR-150 53x18mm/50g(1.8oz).
Specifications
|
DCR-250 Super Macro/Close-Up lens
You can simply "Snap On" DCR-250 Super Macro lens onto the filter
threads of LA-DC58H Canon lens adapter.
Shooting distance from the object ;109mm(∞) in maximum telephoto zoom.
Magnification: 8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Zoom capability: 3x - 6x
Front filter size: 49mm
Rear threads size: 43mm
Size/Weight: DCR-250 53x18mm/60g(2.1oz).
Specifications
(480KB)
(3400KB)
(600KB)
(3600KB)
|
|
|
|
Click camera for actual comparison images.
|
|
Click camera for actual comparison images.
|
MSN-202 Super Macro/Close-Up lens
You can simply "Snap On" MSN-202 Super Macro lens onto the LA-DC58H
Canon lens adapter by using a universal mount UAC3500 and it will be able
to take macro images with minimum distortion at the maximum telephoto position
of PowerShot G9/G7 camera.
(Shooting distance from the object ;32mm(∞) in maximum telephoto zoom.)
Magnification: 25-Diopter
Lens construction: 3G/4E Optical coated glass elements.
Zoom capability: 4x - 6x
Front filter size: None
Rear threads size: 37mm
Size/Weight: MSN-202 42x22mm/60g(2.1oz).
UAC3500 Universal adapter is Included in MSN-202.
|
MSN-505 Super Macro/Close-Up lens
With MSN-505 Super Macro lens attached, the camera captures an intricate tiny object like 5mm x 4mm for a frame-filling enlarged close-up image from the distance of 18.5mm(∞) to the object at the maximum telephoto position.You can simply "Snap On" MSN-505 Super Macro lens onto the filter threads of LA-DC58H Canon lens adapter by using a universal mount UAC3500 and it will be able to capture macro images with minimum distortion at the maximum telephoto position of PowerShot G9/G7 camera.
Magnification: 33-Diopter
Lens construction: 3G/4E Optical coated glass elements.
Zoom capability: 5x - 6x
Front filter size: None
Rear threads size: 37mm
Size/Weight: MSN-505 42 x 24mm/86g(3oz).
UAC3500 Universal adapter is Included in MSN-505.
|
|
|
|
RA5258A adapter ring
 |
|
RA7258 adapter ring
 |
| This is an adapter ring required for mounting DCR-1542PRO, DCR-1850PRO onto the LA-DC58H Canon lens adapter. |
This is an adapter ring required for mounting DCR-5320PRO 3-in-1 High Definition
Macro conversion lens onto the LA-DC58H Canon lens adapter. |
