* 14 models are compatible with HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E AVCHD Camcorders

Captures a super panoramic view in high-definition image quality

Click lens for actual comparison images.



HDP-2800ES High Definition
Diagonal Fisheye conversion Lens 0.28x

The HDP-2800ES lens is a conversion lens for capturing an ultra wide angle image in using with the High Definition Digital camcorder. The lens is particularly designed to be in focus through the whole zoom range of up to 5x*. The lens is made of the high index optical glass in 3-group/3-element formula, and it's made in compact size and light weight. It achieved a high resolution power of 475 lines/mm at center (MTF30%). Mounting on the wide-angle lens of f=26mm or less (35mm film equivalent) focal length, it will be possible to shoot the scene of 180-degree diagonal**.

The two adapter rings of 37mm and 43mm come with the lens in the original factory package for use with the same filter sized lenses.

* The 5x zoom compatibility mentioned above is based on the actual test data made with the under 10x zoom HD camcorder, and depending upon the model of camera lens you use, effective zooming may become less than 5x. For finding the suitable camera models please visit our Raynox Home Page and see the Cross Reference Table.
** A designing calculation figure.


Specifications
  PAGE TOP








Click lens for actual comparison images.







The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.





HDP-7700ES High Definition
Super-Telephoto conversion Lens 3.0x

Finally, we are able to introduce an ultimate telephoto lens of 3.0 times high powered yet constructed in compact measurements of 92mm length (without Lens Shade) x 58mm outside diameter (at the largest). Thanks to the State-of-the-art lens designing formula developed here in Tokyo Lab, the new 3-group/5-element construction of high index optical glasses reached up to a high image standard of 220 lines/mm resolution power at center (MTF30%) with three times high powered telephoto magnification. It never reached before. Adding the lens on SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E AVCHD cameras makes it possible to shoot an ultra telephoto picture like the one taken with a 894mm focal length lens, equivalent in 35mm format.


Magnification: Nominal 3.0x
Actual 3.0x/Diagonal, 3.0x/Horizontal
Lens construction: 3G/5E Optical coated glass elements
Minimum focusing distance: 8m/3.5m(Tele-macro mode)
Effective zooming without vignetting: 9x - 10x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 92 x 58mm/218g(7.68oz)

Accessories included: LS-055 Lens Shade, Lens caps, Lens pouch, 5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size.

Specifications

Comparison movie taken with the HDP-7700ES on
or without at the same distance
(16:9 Wide mode - Taken with SONY HDR-CX550V,
HDR-SR12 AVCHDcam)

PAGE TOP







Click lens for actual comparison images.


HD-2200PRO-LE+(Plus)


The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.




HD-2205PRO/HD-2200PRO-LE+(Plus)(Black model)
High Definition 2.2x Telephoto Conversion Lens

The model HD-2205PRO/HD-2200PRO-LE+(Plus) High-Definition Super Telephoto Conversion lens is made of the hi-index coated optical glass elements with new concept of lens designing using two-group/four-element lens formula. This new concept of lens designing made it possible to achieve an amazing high definition Telephoto lens of the 200 lines/mm resolution power at center (MTF30%). Adding the lens on SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E AVCHD cameras makes it possible to shoot an ultra telephoto picture like the one taken with a 646mm focal length lens, equivalent in 35mm format.


Magnification: Nominal 2.2x
Actual 2.17x/Diagonal, 2.17x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 4.5m/2.5m(Tele-macro mode)
Effective zooming without vignetting: 6x - 10x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 76 x 59mm/105g(3.7oz)

Accessories included: LS-055 Lens shade, Lens caps, Lens pouch, 5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size, Instruction manuals.
LS-055 Lens shade is included with HD-2205PRO and HD-2200PRO-LE+(Plus).

Specifications


VIDEO CLIP 2000KB
VIDEO CLIP 3000KB
Comparison movie taken with the HD-2205PRO on or without at the same distance.
(16:9 Wide ratio)

VIDEO CLIP 2000KB
VIDEO CLIP 3000KB
Comparison movie taken with the HD-2205PRO on or without at the same distance.
(16:9 Wide ratio)
PAGE TOP






Click camera for actual comparison images.






 Raynox lens shade: model LS-082
Weight: 69g.(2.4oz)

DCR-2025PRO 2.2x
High Quality Telephoto Conversion Lens
DCR-2025PRO lens extends the focal length of SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E zoom lens to 655mm* Super telephoto !*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula. 260 lines/mm resolution power at center (MTF30%)
Model RA6252(included accessory) and RA5237B Raynox adapter ring(sold separately) for 37mm filter size are required for use with the DCR-2025PRO + SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E cameras.
*35mm film equivalent in 16:9 ratio.


Magnification: Nominal 2.2x
Actual 2.2x/Diagonal, 2.2x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 4.5m/2.5m(Tele-macro mode)
Effective zooming without vignetting: 6x - 10x zoom
Front filter size: 82mm
Mounting threads: 62mm
Size/Weight: 123 x 85mm/275g(9.7oz)

Accessories included: LS-082 Lens shade, Lens caps, Lens pouch, 4-adapter rings 43mm/52mm/55mm/58mm filter size, Instruction manuals.

Specifications



The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.

PAGE TOP










Click camera for actual comparison images.

DCR-1542PRO/DCR-1541PRO 1.54x
HD Telephoto Conversion Lens

DCR-1542PRO/DCR-1541PRO lens extends the focal length of SONY HDR-CX550V/550VE, HDR-XR550V/550VE zoom lens to 458mm telephoto lens!*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula.
This new concept in designing the lens made it possible to achieve an amazing high definition telephoto lens of the 340 lines/mm resolution power at center (MTF30%), low dispersion and the increased light transmittance at fringe area.
It is necessary to mount RA5237B adapter ring (Included in DCR-1542PRO/DCR-1541PRO) when mounting the lens on the SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E cameras.
There is no difference in the quality of lens between DCR-1542PRO, DCR-1541PRO and DCR-1540PRO.
RA5237B adapter ring is Not Included in DCR-1540PRO.
*35mm film equivalent in 16:9 ratio.

Magnification: Nominal 1.54x
Actual 1.54x/Diagonal, 1.54x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 2.5m/1.5m(Tele-macro mode)
Effective zooming without vignetting: 3x - 10x zoom
Front filter size: 67mm
Mounting threads: 52mm
Size/Weight: 67 x 71mm/240g(8.5oz)
Accessories included in DCR-1542PRO : 3-Adapter rings 37mm/43mm/46mm filter size, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-1541PRO : 3-Adapter rings 37mm/43mm/55mm filter size, Lens pouch, Lens caps, Instruction manuals.

Specifications
PAGE TOP


hd3032pro


Click camera for actual comparison images.




The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
HD-3035PRO High Definition
Semi-Fisheye Conversion Lens 0.3x

The model HD-3035PRO Semi-Fish Eye conversion lens is designed to broaden the angle of view, including 180% more area in the picture, when attached to the lens of SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E High Definition Camcorders.

The HD-3035PRO has achieved an amazing high definition standard of 520 lines/mm resolution power at center (MTF30%) in the Semi-Fish Eye formula.

The HD-3035PRO can be used as semi-fisheye. It may create vignetting at f=3.8mm(max wideangle position). Vignetting may disappear at f=5.4mm(about 1.5x) by zooming and its
magnification becomes about 0.6x horizontal.

Magnification: Nominal 0.3x
Actual 0.34x/Diagonal, 0.44x/Horizontal(4:3ratio)
Lens construction: 2G/2E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1.5x - 5x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 45 x 70mm/143g(5.0oz)

Accessories included: LS-03W Lens shade mask, Lens caps, Lens case, 5-adapter rings 27mm/30mm/30.5mm /34mm/43mm filter size. Instruction manuals.

LS-03W Lens shade mask is included with HD-3035PRO.

Specifications
PAGE TOP





Click camera for actual comparison images.




HD-6600PRO-37 High Definition
Wideangle Conversion Lens 0.66x

The lens is made of hi-index optical glasses, 3-group/3-element, fully coated for non-distortion(-1.3%) and sharp images. It's an ideal accessory lens for professionals and advanced amateurs shooting in tight place.
Mount the lens directly on the 37mm filter threads of SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E High Definition Camcorders.

Magnification: Nominal 0.66x
Actual 0.66x/Diagonal, 0.66x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 6x zoom
Front filter size: 72mm
Mounting threads: 37mm
Size/Weight: 43 x 76mm/175g(6.2oz)
Accessories included: Lens caps, Lens case, Instruction manuals. .
16:9 mode in the max. wideangle position:
Please use at "Active Mode" under which image stabilization is ON.
Slight vignetting may occur when used at "Standard Mode" or image
stabilization is OFF. Even at "Active Mode", if a camera is largely shaken, instantaneous vignetting may occur at a corner in rare cases.
4:3 mode in the max. wideangle position: Vignetting may occur in all corners.


Specifications
PAGE TOP



Specifically designed for using effectively with Super Wide-zoom lens incorporated AVCHD camera

Click camera for actual comparison images.


HDS-680 High Definition Wideangle Conversion Lens 0.67x
The HDS-680 wide-angle lens is specifically designed for using effectively with wide-zoom lens incorporated AVCHD camera models.
The lens is particularly designed to be in focus through the whole zoom range of up to 10x. The lens is made of the high index optical glass in 2-group/2-element formula, and it's made in compact size and light weight.
It achieved a high resolution power of 375 L/mm at center (MTF30% designed figure). The five adapter rings of 27mm, 30mm, 30.5mm, 34mm and 43mm come with the lens in the original factory package for use with the same filter sized cameras.

Mount the lens directly on the 37mm filter threads of SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E High Definition Camcorders.


Magnification: Nominal 0.67x
Actual 0.53x/Diagonal, 0.67x/Horizontal
Lens construction: 2G/2E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 10x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 30 x 66mm/125g(4.4oz)
Accessories included: Lens caps, Lens case, 5-adapter rings 27mm/30mm/30.5mm /34mm/43mm filter size, Instruction manuals.
HDS-680 has been replaced by HDS-680K in April 2017
Specifications
PAGE TOP





Click camera for actual comparison images.



DCR-150 Macro Conversion Lens
You can simply "Snap On" DCR-150 Macro lens onto the RA4337A adapter ring. The shooting distance to the object is about 210mm and the picture size would be 24.5mm width in 16:9 Video mode.

It is necessary to mount RA4337A adapter ring (sold separately from us) when mounting the lens on the SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E.

Magnification: 4.8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Smallest field size: 24.5mm in maximum telephoto position
Effective zooming without vignetting: 3x -10x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/50g(1.8oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.

Specifications
PAGE TOP





Click camera for actual comparison images.



DCR-250 High Power Macro Conversion Lens
You can simply "Snap On" DCR-250 Macro lens onto the RA4337A adapter ring. The shooting distance to the object is about 109mm and the picture size would be 14.7mm width in 16:9 Video mode.

It is necessary to mount RA4337A adapter ring (sold separately from us) when mounting the lens on the SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E.

Magnification: 8-Diopter
Lens Construction: 2G/3E Optical coated glass elements
Smallest field size: 14.7mm in maximum telephoto position
Effective zooming without vignetting: 3x -10x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/60g(2.1oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.

Specifications
PAGE TOP





Click camera for actual comparison images.

WMV FILE 8900KB
MPEG-4 8400KB

MSN-202 Super Macro Conversion Lens
The combination of MSN-202 and SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E makes it easy to capture a tiny object like 5.3mm width for a frame-filling enlarged close-up image from the distance of 32mm to the object at the maximum telephoto position.

Magnification: 25-Diopter
Lens construction: 3G/4E Optical coated glass elements
Smallest field size: 5.3mm in maximum telephoto position
Effective zooming without vignetting: 4x -10x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 22 x 42mm/60g(2.1oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
PAGE TOP





Click camera for actual comparison images.

WMV FILE 8900KB
MPEG-4 8400KB

MSN-505 Super Macro Conversion Lens
With MSN-505 Super Macro lens attached, the camera captures an intricate tiny object like 4.2mm width for a frame-filling enlarged close-up image from the distance of 18.5mm to the object at the maximum telephoto position.

Magnification: 32-Diopter
Lens construction: 3G/4E Optical coated glass elements
Smallest field size: 4.2mm in maximum telephoto position
Effective zooming without vignetting: 4x - 10x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 26 x 42mm/86g(3oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
PAGE TOP



PFR-037MC Lens Protector Filter
The filter is designed to protect your valuable SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E High Definition Camcorder lens from finger prints, dust and other dirt or scratches. The multi-layer coated surfaces will help maintain the original optical performance of your camera.
SONY HDR-CX550V/550VE, HDR-XR550V/550VE, HXR-MC50/50E, HXR-MC50/50E AVCHDcam with PFR-037MC may cause slight vignetting in 4:3 still mode.

Mounting threads: 37mm Pitch0.75
Coatings: Multi-Layer Coated.
PAGE TOP


The cosmetic design may change without a prior notice.
There will be no reduction of light value when these conversion lenses are attached on the camera's lens(Except DCR-150, DCR-250, MSN-202, MSN-505 macro lenses.)
Depending upon the condition of shooting, especially when the lighting is not bright enough, there may be possibility of creating a flare effect which reduces the image quality. When the conversion lens is attached, please make sure that the object is under the bright condition.
Raynox telephoto conversion lenses are designed to use at maximum Telephoto position of  camera's zoom lens, unless specified otherwise.
Raynox wideangle conversion lenses are designed to use at maximum wideangle position of  camera's zoom lens unless specified otherwise.
Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image.
Remote control function may not work properly with conversion lens attached.
Internal video light/flash may not function with conversion lens attached.
When using the zoom-compatible wide angel lens at the telephoto end of camera lens, it must be done under a bright lighting environment, not indoor or poor lighting condition. Otherwise, it will reduce the image quality.
An extra caution must be paid to protect the sticking out long lens by hands in carrying around and using the camera with a telephoto lens on.
To protect the camera from an accidental damage please remove the Conversion Lens before moving the camera and Do not carry around the camera with the Conversion lens attached.
The lens is neither made for dust-free nor moisture/water-proof.
All of Raynox conversion lenses are proudly made in Japan. At our wholly owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
