Click lens for actual comparison images.
The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably. |
HDP-7700ES High Definition
Super-Telephoto conversion Lens 3.0x
Finally, we are able to introduce an ultimate telephoto lens of 3.0 times high powered yet constructed in compact measurements of 92mm length (without Lens Shade) x 58mm outside diameter (at the largest). Thanks to the State-of-the-art lens designing formula developed here in Tokyo Lab, the new 3-group/5-element construction of high index optical glasses reached up to a high image standard of 220 lines/mm resolution power at center (MTF30%) with three times high powered telephoto magnification. It never reached before. |
Magnification: Nominal 3.0x
Actual 3.0x/Diagonal,
3.0x/Horizontal
Lens construction: 3G/5E Optical coated glass elements
Minimum focusing distance: 5m(Tele-macro mode)
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 92 x 58 mm/218g(7.68oz)
Accessories included: Lens Shade, Lens caps, Lens pouch,
5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size.
Specifications
The lens may create darkening corners. Please see actual images taken with HDP-7700ES + SD1 camera. |
PAGE TOP |
|
|
| |

|
HD-2205PRO
Click camera for actual comparison images.
HD-2200PRO-LE+(Plus)(Black model)
Raynox lens shade: model LS-055(Sold separately)
Weight: 37g.(1.3oz) |
|
HD-2205PRO/HD-2200PRO-LE+(Black model)
High Definition
2.2x Telephoto Conversion Lens
The model HD-2205PRO/HD-2200PRO-LE+(Plus) High-Definition Super Telephoto Conversion
lenses are made of the hi-index coated optical glass elements with new
concept of lens designing using two-group/four-element lens formula. This
new concept of lens designing made it possible to achieve an amazing high
definition Telephoto lens of the 200 lines/mm resolution power at center (MTF30%).
Specifications
*35mm film equivalent.
|
Magnification: Nominal 2.2x
Actual 2.17x/Diagonal, 2.17x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 3.5m(Tele-macro mode)
Effective zooming without vignetting: 7x-12x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 76 x 59mm/105g(3.7oz)
Accessories included: LS-055 Lens Shade, Lens caps, Lens pouch.
16:9 mode max. telephoto: No vignetting in (under scanning) mode and still image mode
|
 |
|
Comparison movie taken with the HD-2200PRO on or without at the same distance.
(16:9 Wide mode） |
|
 |
|
Comparison movie taken with the HD-2200PRO on or without at the same distance.
(16:9 Wide mode with 20x Digital zoom） |
|
| PAGE TOP |
  |
Click camera for actual comparison images.
 |
|
DCR-1542PRO/DCR-1541PRO 1.54x
HD Telephoto Conversion Lens
DCR-1542PRO/DCR-1541PRO lens extends the focal length of HDC-SD1/ HDC-DX1 zoom lens
to 710mm telephoto lens!*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula. This new concept in designing a unique lens made it possible to achieve
an amazing high definition telephoto lens of the 340 lines/mm resolution power at center (MTF30%), low dispersion and the increased light transmittance at fringe area.
It is necessary to mount RA5243B adapter ring (Included in DCR-1542PRO/DCR-1541PRO)
when mounting the lens on the Panasonic HDC-SD1/ HDC-DX1 cameras.
There is no difference in the quality of lens between DCR-1542PRO/DCR-1541PRO and DCR-1540PRO.
RA5243B adapter ring is Not Included in DCR-1540PRO.
*35mm film equivalent.
|
|
Magnification: Nominal 1.54x
Actual 1.54x/Diagonal, 1.54x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 2.5m(Tele-macro mode)
Effective zooming without vignetting: 4x - 12x zoom(16:9 mode)
Front filter size: 67mm
Mounting threads: 52mm
Size/Weight: 67 x 71mm/240g(8.5oz)
Accessories included in DCR-1542PRO : 3-Adapter rings 37mm/43mm/46mm filter size, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-1541PRO : 3-Adapter rings 37mm/43mm/55mm filter size, Lens pouch, Lens caps, Instruction manuals.
Specifications |
| PAGE TOP |
  |
Click camera for actual comparison images.
|
|
HD-6600PRO-43 High Definition
Wideangle Conversion Lens 0.66x
The model HD-6600PRO-43 high definition Wideangle conversion lens is made
of the high index optical glass with new concept of lens designing
using a three-group/three-element lens formula. This new concept in designing
the lens made it possible to achieve an amazing high definition wideangle
lens of 350 lines/mm resolution power at center (MTF30%).
Direct mounting on the camera's front ring. |
Magnification:
Nominal 0.66x
Actual 0.66x/Diagonal, 0.66x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Distortion ratio: -1.3%
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 8x zoom
Front filter size: 72mm
Mounting threads: 43mm
Size/Weight: 39 x 76mm/178g(6.3oz)
Accessories included: Lens caps, Lens pouch.
Specifications |
| PAGE TOP |
  |
Click camera for actual comparison images.
|
|
DCR-731/DCR-730 Wideangle Conversion Lens 0.7x
DCR-731/DCR-730 lens broadens an angle of view 37% more than the original camera
lens gets. The lens is made of high index optical glass elements which obtain the maximum resolution power of 375 lines/mm at center (MTF30%), It's compatible with whole zoom area and stays in focus.
It is necessary to mount RA5243B adapter ring (Included in DCR-731)
when mounting the lens on the HDC-SD1/ HDC-DX1 cameras.
There is no difference in the quality of lens between DCR-731 and DCR-730.
RA5243B adapter ring is Not Included in DCR-730.
|
Magnification:
Nominal 0.7x
Actual 0.71x/Diagonal, 0.75x/Horizontal
Lens construction: 2G/2E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 12x zoom
Front filter size: None
Mounting threads: 52mm
Size/Weight: 29 x 66mm/130g(4.6oz)
Accessories included in DCR-731: 3-Adapter rings, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-730 : Lens pouch, Lens caps, Instruction manuals.
Specifications |
| PAGE TOP |
  |
Click camera for actual comparison images.
 The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
(Model LS-03W is included in RAYNOX LS-03W-K
Lens Shade Mask Kit which is sold separately.)
|
|
HD-3035PRO/HD-3032PRO High Definition
0.3x Semi-Fisheye Conversion Lens
The model HD-3035PRO/HD-3032PRO Semi-Fish Eye conversion lens is designed to broaden the angle of view, including 180% more area in the picture, when attached to the lens of HDC-SD1/ HDC-DX1 High Definition Camcorders.
The HD-3035PRO/HD-3032PRO has achieved an amazing high definition standard of 520 lines/mm resolution power at center (MTF30%) in the Semi-Fish Eye formula.
(There is no quality difference between HD-3035PRO and HD-3032PRO lens.)
Model RA3743 adapter ring(Included) is required for use with the HD-3035PRO/HD-3032PRO
+ HDC-SD1/ HDC-DX1 cameras.
A slight vignetting may occur in under scanning mode and still image
mode at wideangle zoom end.
|
Magnification: Nominal 0.3x
Actual 0.34x/Diagonal, 0.44x/Horizontal(4:3mode)
Lens construction: 2G/2E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 6x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 45 x 70mm/143g(5.0oz)
Accessories included with HD-3035PRO: LS-03W Lens shade mask, Lens caps, Lens case, 5-adapter rings
27mm/30mm/30.5mm/37mm/34mm/43mm filter size.
Accessories included with HD-3032PRO: Lens caps, Lens case, 5-adapter rings
27mm/30mm/30.5mm/37mm/34mm/43mm filter size.
LS-03W Lens shade mask is included with HD-3035PRO.
LS-03W Lens shade mask is Not included with HD-3032PRO.
Specifications |
| PAGE TOP |
  |
Click camera for actual comparison images.
|
|
DCR-5000 Super Wideangle Lens Attachment, 0.5x
Production discontinued - July 2008
DCR-5000 lens broadens angle of view 100% more than original camera lens.
* Compatible with HDC-SD1/ HDC-DX1 HDV camcorders.
Model RA5243B Raynox adapter ring(sold separately) for 43mm filter size
is required for use with the DCR-5000 + HDC-SD1/ HDC-DX1 cameras.
RA5243B adapter ring is Not Included.
|
|
Magnification: Nominal 0.5x
Actual 0.44x/Diagonal, 0.5x/Horizontal
Lens construction: 1G/1E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 3x zoom
Front filter size: None
Mounting threads: 52mm
Size/Weight: 26 x 90mm/140g(4.9oz)
Accessories included: Lens caps, Lens pouch.
DCR-5000 is designed to focus when the zoom lens is set in 1-3x wideangle
position. |
|
|
PAGE TOP |
  |
Click camera for actual comparison images.
|
|
DCR-150 Macro Conversion Lens
You can simply screw in DCR-150 Macro lens onto the HDC-SD1/ HDC-DX1's
43mm front ring directly. The shooting distance to the object is about
210mm and a 16mm wide object taken would spread to full frame picture in
Tape recoding mode.
Direct mounting on the camera's front ring.
Specifications |
|
Magnification: 4.8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 2x - 12x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/50g(1.8oz)
Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.
|
| PAGE TOP |
 |
Click camera for actual comparison images.
|
|
DCR-250 High Power Macro Conversion Lens
You can simply screw in DCR-250 Macro lens onto the HDC-SD1/ HDC-DX1's 43mm front ring directly. The shooting distance to the object is about 109mm and a 10mm wide object taken would spread to full frame picture in Tape recoding mode.
Direct mounting on the camera's front ring.
Specifications |
|
Magnification: 8-Diopter
Lens Construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 3x - 12x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/60g(2.1oz)
Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.
|
| PAGE TOP |
  |
Click camera for actual comparison images.
|
|
MSN-202 Super Macro Conversion Lens
The combination of MSN-202 and HDC-SD1/ HDC-DX1 display panel makes it
easy to capture a tiny object from the distance of 32mm to the object at
maximum telephoto position and the picture size would be 3mm width in Tape
recoding mode.
Model RA3743 Raynox adapter ring(sold separately) for 43mm filter size
is required for use with the MSN-202 + HDC-SD1/ HDC-DX1 cameras.
RA3743 adapter ring is Not Included. |
Magnification: 25-Diopter
Lens construction: 3G/4E Optical coated glass elements
Image size: 1.9mm width
Effective zooming without vignetting: 6x - 12x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 22 x 42mm/60g(2.1oz)
Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
|
| PAGE TOP |
 |
Click camera for actual comparison images.
|
|
MSN-505 Super Macro Conversion Lens
With MSN-505 Super Macro lens attached, the camera captures an intricate
tiny object like 2mm width for a frame-filling enlarged close-up image
from the distance of 18.5mm to the object at the maximum telephoto position.
Model RA3743 Raynox adapter ring(sold separately) for 43mm filter size
is required for use with the MSN-202 + HDC-SD1/ HDC-DX1 cameras.
RA3743 adapter ring is Not Included.
|
Magnification: 32-Diopter
Lens construction: 3G/4E Optical coated glass elements
Image size: 1.4mm width
Effective zooming without vignetting: 8x -12x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 26 x 42mm/86g(3oz)
Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
|
| PAGE TOP |
  |
 |
|
PFR-043MC Lens Protector Filter for SD1 & DX1
The filter is designed to protect your valuable HDC-SD1, HDC-DX1 High Definition
Camcorder lens from air pollution or scratches. The multi-layer coated
surfaces will help maintain the original optical performance of your camera.
|
|
|
Thread size: 43mm Pitch0.75
Coatings: Multi-Layer Coated.
Direct mounting on the camera's front ring. |
|
|
